Home > Air Forging Hammer > C41-16KG > Air Hammer

Air Hammer

  • Air Forging Hammer
  • Air Hammer
  • Product Name:

    Air Hammer
  • Model No.:

    C41-16KG
  • Minimum Order:

    1

Product Abstract:

he series of air hammer with small size,low noise,simple structure,easy operation,flexible movement and convenient to transit,installation,maintenance,the type is widely used for various of free forging works, such as drawing-out, upsetting, punching, chiseling, forging welding, bending and twisting. It is also used for open-die forging in bolster dies.It is suitable for free forging works of all kinds of different shape parts,especially suitable for village township enterprise and self –employed forge small agricultural tools ,for example sickle,horseshoes,spike,hoe etc.At the same time ,the industrial enterprise use the air hammer to forge the steel ball,scaffold and many other factories&mines ,construction supplies.In addition the series air hammer is very commonly professional blacksmith’s iron tools that can install all kinds of mould to forge a variety of wrought iron flowers,birds and other beautiful decoration.


Product Description

SPECIFICATION

UNIT

C41-16kg single

Max. hit energy

kj

0.18

Height of working area

mm

180

Hit number

min-1

258

Dimension of top and bottom die surface(LxW)

mm

70 x 40

Max. square steel can be forged

mm

20 x 20

Max. round steel can be forged(Diameter)

mm

¢22

Motor  power

kw

1 phase 1.5/220
3 phase 1.5/380

Speeds of motor

r.p.m

1440

Base plate weight

kg

-------

Total weight

kg

240

Overall dimensions(L*W*H)

mm

660*420*970
