Home > Air Forging Hammer > C41-55KG > Air Hammer

Air Hammer

  • Air Hammer
  • Product Name:

    Air Hammer
  • Model No.:

    C41-55KG
  • Minimum Order:

    1

Product Abstract:

Air hammer is widely used for general forging works, such as drawing-out, upsetting, punching, chiseling, forging, welding, bending and twisting. It is also used for forge in bolster dies. Air hammer is also called forging hammer, power hammer falling weight at16kg, 20kg, 25kg, 40kg, 55kg, 75kg ,150kg mainly for artistic wrought iron, artistic forging, blacksmith, agriculture tools and small open die forging parts.


Product Description
SPECIFICATION UNIT C41-55kg
Max.   hit  energy kj 0.7
Height  of  working  area mm 265
Hit  number  min-1 230
Dimension of top and bottom die surface(LxW) mm 120 x 55
Max.   square  steel  can  be  forged mm 52  x  52
Max.   round  steel  can  be  forged(Diameter) mm ¢68
Motor    power kw 5.5
Speeds  of  motor r. p. m 1440
Anvil  weight kg 600
Total  weight kg 1700
Overall  dimensions(L*W*H) mm 1320*670*1620
