Ck6130 Small Flat Bench Cutting Horizontal Metal Machine Desktop Turning Tool Vertical Professional Mini Wood Slant Bed CNC Lathe

Home > Lathe Machine > CNC Lathe Machine > Ck6130 Small Flat Bench Cutting Horizontal Metal Machine Desktop Turning Tool Vertical Professional Mini Wood Slant Bed CNC Lathe

Original Picture

Product Name:
Ck6130 Small Flat Bench Cutting Horizontal Metal Machine Desktop Turning Tool Vertical Professional Mini Wood Slant Bed CNC Lathe
Model No.:
CK6163
Minimum Order:
1

Product Abstract:

The CK6130 series CNC horizontal lathe features high precision, high power, high rigidity, and other characteristics. Its main components and structure have been optimized designed, making it the preferred equipment for processing shafts, discs, sleeves, special-shaped surfaces, and screw-type workpieces.

Product Description

Equipped with GSK980TB3 CNC system and all-digital AC servo system, both X and Z axes are controlled in a semi-closed-loop manner. The ball screw pair uses precision C3-grade ball screws, and the electrical components are all from well-known imported or domestic brands, meeting CE or domestic 3C certification requirements.
Before leaving the factory, the machine tool undergoes strict inspections according to the inspection procedures, with each machine tool being tested for the positioning

accuracy and repeatability of the X and Z axes using a laser interferometer to ensure the accuracy, stability, and reliability of the machine tool.

Items	Unit	Specifications
Items	Unit	CK6130
Max. rotation diameter over bed	mm	φ300
Max.rotation diameter over pallet	mm	φ120
Max. workpiece length	mm	400
Rail width	mm	300
Spindle nose		A2-5
Spindle speed mode		Frequency stepless speed
Spindle speed range	r/min	150-2200
X axis travel	mm	300
Z axis travel	mm	500
Spindle bore	mm	Φ48
Spindle hole bore taper		MT5
Chuck diameter		6”
Main motor power	kw	4.0
Rapid speed	m/min	6/8
Turret form		4-station electric turret
repeat positioning accuracy	mm	X：0.01 Z：0.01
Workpiece accuracy		IT6-IT7
Workpiece surface roughness		Ra1.6
Tailstock quill diameter	mm	φ60
Tailstock quill stroke	mm	100
Tailstock quill taper		MT4
repeat positioning accuracy	mm	0.008
Arbor section	mm	20×20
Overall dimensions(L×W×H)	mm	2460×1460×1830
Net weight	kg	950

Standard Configuration:

1- CNC system: GSK928;
2- 6”Hydraulic Chuck;
3- 4-station electric tool post;
4- Automatic lubrication system;
5- Work lighting system;
6- Turning cooling system;
7- Cast iron stand.

8-manual tailstock;
