Horizontal Universal Milling Machine
Product Name:
Horizontal Universal Milling MachineModel No.:
X6132Minimum Order:
1
Product Abstract:
1. Universal knee-type milling machine 2.The worktable size is 1320x320mm 3.The Max.load of table is 500kg 4.The spindle speed range is 30-1500rpm 5.The spindle speed step is 18 steps 6. Easy operation, high stability. 7. Ball screw be ordered according demand of clients.
- Product Description
Specification
Units
X6132
X6132BH
Table size
mm
320x1325
320x1600
Longitudinal travel(manual/auto)
mm
700/680
900/800
Cross travel(manual/auto)
mm
255/240
255/240
Vertical travel(manual/auto)
mm
320/300
410/390
Work table swivel angel
±45
±45
Cutting feed speed
mm/min
X:19--950 Y:19--950
Z:6.3--317X:19--950 Y:19--950
Z:6.3--317Rapid feed speed
mm/min
X-2300 Y-2300 Z-770
X-2300 Y-2300 Z-770
Spindle speed range
r/mm
30-1500
30-1500
Spindle speed step
-
18 (steps)
18 (steps)
Distance between spindle
axis table surfacemm
30~350
30~440
Power of spindle motor
kw
7.5
7.5
Feed motor power
kw
2.2
2.2
Overall dimension(LxWxH)
mm
2300x1770x1600
2300x2050x1800
N.W/G.W
kg
2650/2950
2940/3240
