Hydraulic Radial Drilling Machine
Product Name:
Hydraulic Radial Drilling MachineModel No.:
Z3080X20Minimum Order:
1
Product Abstract:
The radial drilling machine of Model Z3080×20 is one of the large multi-purpose equipments, which is characterized by the high efficiency , close tolerance, hydraulic pressure transmission. Drilling diameter of 80mm is used to drill, expand, ream, groove, tap the middle and large parts and even to bore the holes if it is equipped with the necessary devices. This type of machine tool is easy to operate and is an ideal boring equipment in the manufacturing and repair fields; and it has been awarded the top quality model of Shandong Province many times and sells well at home and abroad.
- Product Description
Max drilling diameter
80mm
Distance from spindle axis to column
Max
2000mm
Min
500mm
Distance from spindle nose to working surface of base plate
Max
2000mm
Min
550mm
Taper of spindle (Mores No.)
6#
Spindle travel
450mm
Spindle travel
16-1250rpm
Range of spindle feeds
0.04-3.2mm/r
Horizontal travel of spindle head
2000mm
Max. torque of spindle
160kw-m
Diameter of outer column
550mm
Power of main drive motor
7.5kw
Overall dimensions of machine (L*W*H)
3730x1400x3828(mm)
Net weight
11000kg
