Pneumatic Forging Hammer

  • Pneumatic Forging Hammer
  • C41-75KG  Single Forging Hammer

Product Abstract:

Air hammer is widely used for general forging works, such as drawing-out, upsetting, punching, chiseling, forging, welding, bending and twisting. It is also used for forge in bolster dies. Air hammer is also called forging hammer, power hammer falling weight at16kg, 20kg, 25kg, 40kg, 55kg, 75kg ,150kg mainly for artistic wrought iron, artistic forging, blacksmith, agriculture tools and small open die forging parts.


Product Description

SPECIFICATION UNIT C41-75kg
Max. hit energy kj 1
Height of working area mm 300
Hit number  min-1 210
Dimension of top and bottom die surface(LxW) mm 145 x 65
Max. square steel can be forged mm 65 x 65
Max. round steel can be forged(Diameter) mm ¢85
Motor  power kw 7.5
Speeds of motor r.p.m 1440
Anvil weight kg 850
Total weight kg 2800
Overall dimensions(L*W*H) mm 1400*760*1950
