Power Hammer

  • Air Forging Hammer
  • Power Hammer
  • Air Hammer Single With Base Plate C41-25DB
  • Product Name:

    Power Hammer
  • Model No.:

    C41-25KG
  • Minimum Order:

    1

Product Abstract:

The series of air hammer with small size,low noise,simple structure,easy operation,flexible movement and convenient to transit,installation,maintenance,the type is widely used for various of free Forging works, such as drawing-out, upsetting, punching, chiseling, forging welding, bending and twisting. It is also used for forging in bolster dies.It is suitable for free forging works of all kinds of different shape parts.


Product Description

SPECIFICATION

UNIT

C41-25kg single

Max. hit energy

kj

0.27

Height of working area

mm

240

Hit number

min-1

250

Dimension of top and bottom die surface(LxW)

mm

100 x 50

Max. square steel can be forged

mm

40 x 40

Max. round steel can be forged(Diameter)

mm

¢45

Motor  power

kw

1 phase 3/220V
3 phase 2.2/380V

Speeds of motor

r.p.m

1440

Base plate weight

kg

-

Total weight

kg

760

Overall dimensions(L*W*H)

mm

980*510*1200
