1. Adopts overall inclined bed body structure, equipped with high-precision preload Taiwan straight-line rolling guide rail.

The machine has high position accuracy, smooth debris discharge, suitable for high speed & high precision machining.

2. Adopts high-precision spindle bearing group with precision assembly and dynamic balance test to ensure high spindle accuracy, low noise and strong rigidity.

3. Choose the knife tower mode, fast knife replacement speed & high positioning accuracy.

4. In the X and Z direction feed, the servo motor is directly connected to the wire through a large torque and low inertia elastic coupling to ensure positioning accuracy and repeated positioning accuracy.

5. Adopts advanced centralized automatic lubrication device, regular and quantitative automatic intermittent lubrication, stable and reliable work.

6. Domestic hydraulic dial is used.

7. The hydraulic tail seat is processed by manually adjusting the locking and the hydraulic piston top workparts

Main configuration

1.SYNTEC 22TB  absolute value system,

2.12 station power turret,

3. 6-inch hollow hydraulic chuck,

4.Linear rail,

5.Chip conveyor,

6.Alarm lamp,

7.Automatic lubrication,

8.Automatic cooling,

9.Work light.

Technical Parameter
