X6336 Universal Milling MACHINE
Product Name:
X6336 Universal Milling MACHINEModel No.:
X6336Minimum Order:
1
Product Abstract:
The machine is used for cutting metals,it's an universal milling machine.Cylinder mill,round piece mill,shape mill and end mill can be installed on the conical hole of main pivot of the machine,which is suitable for processing plane surface,oblique plane,groove,hole,gear of all kinds of small,medium parts.User can select universal dividing head(a special auxiliary)to process groove of thread.The machine is an ideal processing equipment for machine manufacturing,mold,instrument,automobile motorcyole and other trades
- Product Description
Main specification
X6336
Spindle taper
7:24 ISO 50
Distance from spindle axis to table surface
0-400 mm
Distance from horizontal spindle axis to beam surface
230 mm
Range of spindle speed
12(steps) 60~1800（H） 16(steps) 66~4540（V）r.p.m
Table size
1250 x 360 mm
Table travel(horizontal/cross/vertical)
1000/315/400
Speed of table feed (horizontal/cross)
8(steps)15~370(rapid feed speed 540）mm/min
Speed of table vertical lifting
590 mm/min
T-slot(number/width/spacing)
3/18mm/80mm
Main motor power
3.7(V)/4(H) KW
Power of table automatic feed
750 W
Power of lifter automatic feed
1.1 KW
Coolant pump motor power
90 W
Coolant pump flow
25 L/min
Overall dimension
2220 x 1790 x 2360 mm
Net weight
2400 kg
