Item Name

Unit

Parameter Value

Table size

mm

1370 x 360

T-slots(NXWXD)

3/18/80

Longitudinal travel

mm

900

Cross travel

mm

320

Vertical travel

mm

370

Table longitudinal feed(auto)

stepless

Table cross feed(auto)

stepless

Table vertical feed(auto)

stepless

Distance between spindle nose and table surface

mm

45-415

Spindle taper

7:24 ISO 50

Number of spindle speed

18

Spindle speed range

r.p.m

30-1500

Max.swivel angle of spindle

°

±45°

Spindle travel

mm

85

Main motor power

kw

7.5

X,Y,Z to feed AC servo motor torque

Nm

10   10   10

Overall dimensions

mm

2530 x 1890 x 2380

N.W

kg

3200
