Specifications

XK7130L

XK7130L-B

Worktable size

1000 X 300 mm

1000 X 300

T-Slot No/width/interval

3-16mm-100mm

3-16mm-100mm

Maximum Loading weight

200kg

200kg

X axis travel

600mm

600mm

Y axis travel

380mm

380mm

Z axis travel

450mm

450mm

Distance from spindle nose to table surface

100-550mm

100-550mm

Distance from spindle axis to column surface

370mm

370mm

Spindle taper

BT40(spindle unit)

BT40(spindle unit)

Spindle Maximum rotate speed

3000 r.p.m

6000 r.p.m

Main motor power

3kw(converter motor)

3.7kw(servo motor)

Feed motor

X axis torque

6 N.M

6 N.M

Y axis torque

6 N.M

6 N.M

Z axis torque

10 N.M

10 N.M

Rapid move speed

10 m/min

10 m/min

Cutting feed speed

1-5000 mm/min

1-5000 mm/min

Screw parameter(diameter/pitch of screw)

30mm/6mm

32mm/6mm

Linear guide width X/Y/Z

30mm

35mm

Precision

Positional Accuracy

0.02mm

0.02mm

Repositional accuracy

0.015mm

0.015mm

Steel tapping

NO

YES

Change tools type

Pneumatic

Pneumatic

Use pressure

0.6Mpa

0.6Mpa

Machine weight

1500 kg

1700kg

CNC control System

Overall Dimensions(full guard)

2200x1500x2300

2200x1500x2300
